Universal Matrix 23 Power
Universal Matrix 23 Power
Couldn't load pickup availability
This brilliant 23 LED array is designed to fit in 5” or 6” dome lights made by AAA, ABI, West Marine & Cabin among others. It comes with your choice of G4, Single or Double Contact 15mm Bayonet and Wedge bases which can be coupled to the array by a short “pig-tail”. When you choose which base you have, you only get that base, this product does not include all the bases in one package.
Peel & Stick foam strips are mounted on the back to hold the array in position & the board has a cut-away to accommodate the socket for a perfect fit. This LED will outperform your existing light at 1/8th the power.
Specifications
• 10-30Volts DC Constant Current
• 2.7 watts (0.23amps @ 12V)
• 190 Lumens (comparable to 20w halogen)
• 120 degree beam angle
• 57mm x 57mm
- <
2 Year Warranty
Fit check before ordering
Universal Matrix 23 Power should be matched to the existing fixture before ordering. The product name identifies the bulb or fixture family, but the final fit still depends on base, pin orientation, voltage, color, clearance, and the job the light performs.
| Check | Why it matters |
|---|---|
| Base or socket | G4, bayonet, wedge, festoon, MR11, and E26/E27 bases can look similar but fit differently. |
| Voltage and polarity | Marine DC systems vary, and some installations are sensitive to wiring, dimming, or polarity. |
| Color and use | Warm white, cool white, red, green, and dual-color options solve different cabin, cockpit, and navigation-light jobs. |
| Physical clearance | Tower, side-pin, back-pin, dome, and fixture housings can interfere with lenses or covers. |
Current selectable options
| Current page option | Visible values |
|---|---|
| Contact | Bi-Pin G4, Wedge, Double Contact Bayonet, Single Contact Bayonet, Festoon |
FAQ
Can I choose by bulb family alone?
No. Confirm the exact base, pin direction or offset, lens clearance, and color before ordering.
Is every LED suitable for a navigation light?
No. Navigation lights depend on fixture geometry, visibility sector, lens color, and output pattern. Use a navigation-specific bulb or fixture where required.
For more replacement choices, see LED replacement bulbs.
